Industrial PoE switch
Industrial grade management type 4-optical 8-electrical switch
G500P-5F 5-port full 100Mbps industrial grade PoE switch is a HiSilicon industrial grade management switch series, with industrial grade performance characteristics that can withstand harsh working environments. The product series is rich and the port configuration is flexible, which can meet the usage needs of various industrial fields. The product has a unique industrial grade dedicated management interface, providing a comprehensive security protection system, perfect ring network applications, QoS strategies, and rich VLAN functions. It is easy to manage and maintain, meeting the needs of intelligent manufacturing, metallurgy, mining, electricity, petroleum, chemical, new energy, rail transportation, road transportation, shipbuilding, agriculture and animal husbandry, etc. For complex and high-density environments, it can be widely applied to various networks.
Full 100Mbps Ethernet port
The entire series adopts a full 100Mbps electrical port, which facilitates flexible networking for users and meets the networking needs of various scenarios; All ports support line speed forwarding and have high-speed bandwidth processing capabilities. Port 1 supports IEEE802.3af/at/boe++/bt with a maximum power of 90W, while ports 2-4 support IEEE802.3af/at with a maximum power of 30W per port. Each port allows for the transmission of data packets between connected devices such as computers, sensors, cameras, and other networked devices. Switches manage data flow to ensure efficient communication.
Strong business capabilities
Adopting Hasivo's independent intelligent PSE chip and Hasivo's intelligent CPU chip, it supports industrial working temperature: -40 ℃~80 ℃, industrial working humidity: 10%~90% RH without condensation, and has a unique advanced PoE watchdog function. The PCB board is made of chemical nickel gold board, which has high corrosion resistance and oxidation resistance, and better electrical performance. High specification and long-life Japanese capacitors are selected to greatly improve the service life of the product. The high redundancy system circuit design avoids the impact of external environmental changes on the normal operation of the equipment.
Diverse reliability protection
The switch supports STP/RSTP/MSTP spanning tree protocols to eliminate Layer 2 loops and ensure link backup. It includes security features to protect against various forms of malicious attacks within the spanning tree network. Additionally, it supports both static and dynamic link aggregation, effectively increasing link bandwidth, achieving load balancing, and enhancing link reliability.
