PoE Switch
The Ai series PoE switch automatically detects and supplies power to devices compliant with the IEEE802.3af/at | PoE++| HiPoE standard. It now features integrated HiPoE and PoEdog functions, addressing power supply challenges for high-power outdoor dome cameras, high-power wireless APs, and other such devices. The PogDog function will automatically repair PD devices in the event of an unexpected crash, thus eliminating the need for time-consuming and labor-intensive manual operations, and facilitating intelligent unattended operation.
100Mbps access, gigabit uplink
The full series supports a combination of "100Mbps Ethernet ports and Gigabit optical multiplexing ports", enabling flexible user networking that meets diverse scenario requirements; All ports support line-rate forwarding, providing high-speed bandwidth processing capabilities. HiPoE: Ports 1 and 2 deliver 60W, addressing high-power PD power supply issues, and are compatible with large dome cameras, wireless APs, or smart door locks among other high-power PoE devices. PoEdog: Once PoE is activated, it provides real-time monitoring of PoE device status; in case of any device anomalies, it automatically identifies and supplies power to the PoE devices, ensuring no damage to non-PoE devices. PoE ports feature a priority mechanism, ensuring priority power supply to high-priority ports when power is scarce, preventing device overload.
Strong business capabilities
Supports IEEE 802.1Q VLANs, enabling users to flexibly partition VLANs based on their needs. Supports QoS, offering three priority modes based on ports, 802.1P, and DSCP, alongside four queue scheduling algorithms: Equ, SP, WRR, and SP+WRR. Supports ACL, filtering data packets by configuring matching rules, processing operations, and time permissions, offering flexible security access control policies. Supports the IGMP V1/V2 multicast protocol and IGMP Snooping, fulfilling the needs for multi-terminal high-definition video surveillance and video conferencing access. Supports multicast VLANs and multicast filtering, enabling efficient data transmission, conserving network bandwidth, and reducing network load. Supports port monitoring, mirroring a copy of data packets from the monitored port to the monitoring port for network surveillance. Supports the quadruple binding of IP address, MAC address, VLAN, and port for filtering data packets.
Diverse Reliability Protection Supports STP/RSTP/MSTP spanning tree protocols, eliminates layer 2 loops, and implements link backup. Supports spanning tree security features to protect devices in the spanning tree network from malicious attacks. Supports static and dynamic aggregation, effectively enhances link bandwidth, achieves load balancing, link backup, and improves link reliability. Supports port security, stops learning MAC addresses once the port reaches its maximum learning capacity, to prevent MAC address attacks and manage port network traffic.
